Centralized Oil Mist Collector with fan
The advantages of central filters are a cheaper installation, easier service because of less service points and the possibility to lead the process air through a heat exchanger
The Absolent type A-mist oil mist collectors features one of the most effective systems in the world for cleaning oil mist with extremely low maintenance.
Absolent filter units can usually run for at least one year without requiring a filter change. A-mist filter cassettes can usually be washed resulting in a low total cost of ownership. (does not include HEPA filter)
Low noise level for agreeable working conditions.
| A•mist40TF Technical Data | Metric | Imperial |
|---|---|---|
| (H) Height | 2360 mm | 92.9 in |
| (W) Width | 723 mm | 28.5 in |
| (D) Depth | 1267 mm | 49.9.in |
| Inlet duct Ø | 315 mm | 12.4 in* |
| Weight with dry filters | 385 kg | 840 lbs |
| Motor output, fan motor | 4.0 kW | 5.4 hp |
| Max. airflow | 4000 m³/h | 2350 cfm |
*Inlet duct not included for the US market.
